NON-METAL LASER CUTTING & CARVING MACHINE
DC-6040-N Laser Cutting & Marking Machine
The first independent motorized up & down table, Equipped with rotary attachment, ensuring normal working life of 10 years without deformation.
The fabric arts laser engraving machine can engrave kinds of wine bottles, vase and pencil vase with vivid designs.
Working table：900 * 600mm
Laser power：60~80W
Volume(m3)：1.7
Weight：184kg
Machine body size：148*1140*1100mm
Processing Area：900×600mm
Max Cutting Speed：36m/min
Repeated Accuracy：±0.1mm
Carving Speed：60m/min
Cutting Speed：36m/min
Resolution Accuracy：0.0064mm
Location Accuracy：0.05mm
Machine Total Power：≤1250W
Working Temperature：0°C-40°C
Blowing System：lower blowing system(upper blowing system is available )
Working Power Supply：AC220V±10% 50HZ
Formats：CDR、BMP、PLT、GPEG、DXF、DST
Applied Materials ：Acrylic, LGP, MDF, Plywood, advertisement and decoration material,Template cutting, especially designed for customers demanding high precision.
The first company adopting the self-developed ERP management system, 100% of the materials and parts are tested by precise equipment, each laser tube are age-tested for 8 hours, all finished machines go through an 8-hour running test before delivery.
